BSON Patch

This is an implementation of RFC 6902 JSON Patch[1] written in Java with extended BSON pointers.

This JSON Patch[2] implementation works directly with BSON documents[3] using the MongoDB Java driver implementation of BSON[4].

The code here was forked (copied, renamed, repackaged, modified) from eBay bsonpatch project[5] which, in turn, was ported (forked, renamed, repackaged, modified) from the zjsonpatch project[6].

Tests Passing Test Line Coverage Complexity Duplicate Blocks Pct Duplicate Lines

GitHub Clones Stars[7] Open Issues[8] Last Commit[9] Latest Release[10] Release Date[11] Downloads (All Releases)[11]

Project Home[12]

Description & Use-Cases

  • Java Library to find / apply JSON Patches according to RFC 6902[1].
  • JSON Patch defines a JSON document structure for representing changes to a JSON document.
  • It can be used to avoid sending a whole document when only a part has changed, thus reducing network bandwidth requirements if data (in JSON format) is required to send across multiple systems over network or in case of multi DC transfer.
  • When used in combination with the HTTP PATCH method as per RFC 5789 HTTP PATCH[13], it will do partial updates for HTTP APIs in a standard way.
  • Extended JSON pointer functionality (i.e. reference array elements via a key): /array/id=123/data
    • The user has to ensure that a unique field is used as a reference key. Should there be more than one array element matching the given key-value pair, the first element will be selected.
    • Key based referencing may be slow for large arrays. Hence, standard index based array pointers should be used for large arrays.
  • This library compares two BsonValue[14] inputs and produces a BsonArray[15] of the changes.

Compatible with : Java 8 and above all versions

Complexity

  • To find JsonPatch : Ω(N+M), N and M represents number of keys in first and second JSON respectively / O(summation of la*lb) where la , lb represents JSON Array of length la / lb of against same key in first and second JSON ,since LCS is used to find difference between 2 JSON arrays there of order of quadratic.
  • To Optimize Diffs ( compact move and remove into Move ) : Ω(D) / O(D*D) where D represents number of diffs obtained before compaction into Move operation.
  • To Apply Diff : O(D) where D represents number of diffs

How to use:

Current Version : 0.5.0-RELEASE

Add following to <dependencies/> section of your pom.xml -

<dependency>
  <groupId>io.github.bsonpatch</groupId>
  <artifactId>bsonpatch</artifactId>
  <version>0.5.0-RELEASE</version>
</dependency>

API Usage

Obtaining Json Diff as patch

BsonArray patch = BsonDiff.asBson(BsonValue source, BsonValue target)

Computes and returns a JSON patch (as a BsonArray) from source to target, Both source and target must be either valid BSON objects or arrays or values. Further, if resultant patch is applied to source, it will yield target.

The algorithm which computes this JsonPatch currently generates following operations as per RFC 6902[16] -

  • add
  • remove
  • replace
  • move
  • copy

Apply Json Patch

BsonValue target = BsonPatch.apply(BsonArray patch, BsonValue source);

Given a patch, apply it to source Bson and return a target Bson which can be ( Bson object or array or value ). This operation performed on a clone of source Bson ( thus, source Bson is untouched and can be used further).

To turn off MOVE & COPY Operations

EnumSet<DiffFlags> flags = DiffFlags.dontNormalizeOpIntoMoveAndCopy().clone()
BsonArray patch = BsonDiff.asJson(BsonValue source, BsonValue target, flags)

Example

First Json

{"a": 0,"b": [1,2]}

Second json ( the json to obtain )

 {"b": [1,2,0]}

Following patch will be returned:

[{"op":"move","from":"/a","path":"/b/2"}]

here "op" represents the operation ("move"), "from" represent path from where value should be moved, "path" represents where value should be moved. The value that is moved is taken as the content at the "from" path.

Extended JSON Pointer Example

JSON

{
  "a": [
    {
      "id": 1,
      "data": "abc"
    },
    {
      "id": 2,
      "data": "def"
    }
  ]
}

JSON path

/a/id=2/data

Following JSON would be returned

"def"

Apply Json Patch In-Place

BsonPatch.applyInPlace(BsonArray patch, BsonValue source);

Given a patch, it will apply it to the source BSON mutating the instance, opposed to BsonPatch.apply which returns a new instance with the patch applied, leaving the source unchanged.

This is an extension to the RFC, and has some additional limitations. Specifically, the source document cannot be fully change in place. This means the following operations are not supported:

  • remove with an empty or root path;
  • replace with an empty or root path;
  • move, add or copy targeting an empty or root path.

Tests:

  1. 100+ selective hardcoded different input JSONs , with their driver test classes present under /test directory.
  2. Apart from selective input, a deterministic random JSON generator is present under ( TestDataGenerator.java ), and its driver test class method is JsonDiffTest.testGeneratedJsonDiff().

*** Tests can only show the presence of bugs and not their absence ***

Get Involved

Maintainers
